Anycubic PETG-CF Filament – Syrup Brown

Description

Carbon fibre reinforced PETG | 54±2 MPa tensile strength | 40-250 mm/s print speeds | Syrup Brown 1 kg spool | ACE compatible

Quick Specs

• Print with carbon fibre reinforced PETG in a 1 kg spool of Syrup Brown
• Achieve rigid parts with a bending modulus of 3100±150 MPa
• Run print speeds anywhere from 40 to 250 mm/s
• Handle tougher use with an Izod impact strength of 60±4 kJ/m²
• Connect with ACE-compatible desktop FDM printers fitted with a hardened steel nozzle

Carbon fibre reinforced PETG for functional prints

The Anycubic PETG-CF Filament in Syrup Brown is made for makers who want more from their FDM 3D printer than display models. It combines PETG with carbon fibre reinforcement, giving you a PETG-CF filament suited to brackets, enclosures, jigs and other parts that need to do real work. The 1 kg spool is finished in a warm Syrup Brown (#99403A), so your finished parts look as considered as they perform.

Tired of guessing your print settings?

Dialling in a new filament can eat hours, so this one comes with clear windows to work within. Print with a nozzle temperature of 240-270 ℃ and a bed temperature of 65-70 ℃, and choose a printing speed anywhere between 40 and 250 mm/s depending on whether you value detail or throughput. It is designed for desktop FDM 3D printers with a hardened steel nozzle of 0.4 mm or above, and it is ACE compatible, so it slots into an ACE-based workflow without extra fuss.

Strength and stiffness you can measure

Mechanical performance is published, not implied. You get a tensile strength of 54±2 MPa, a Young's modulus of 2550±100 MPa and a bending strength of 88±2 MPa, backed by a bending modulus of 3100±150 MPa for parts that resist flexing under load. An Izod impact strength of 60±4 kJ/m² (X-Y) and an elongation at break of 12±1% show how the material copes with knocks and strain, which helps you judge whether it suits your design before you commit to a long print.

Know its heat limits and look after your spool

Plan your parts with confidence using the stated thermal data: a melting temperature of 221 ℃, a Vicat softening temperature of 74 ℃ and a heat deflection temperature of 67 ℃ at 0.45 MPa. To get consistent results, dry the filament at 60-65 °C for 6-8 hours in a convection oven before printing. With a density of 1.32 g/cm³ and a melt flow index of 14.1±1.6 g/10 min (190℃/2.16kg), it is well documented for anyone fine-tuning their slicer profile.

Features

• Carbon fibre reinforced PETG (PETG-CF) for functional FDM parts
• 1 kg net weight spool in Syrup Brown (#99403A)
• Tensile strength of 54±2 MPa and bending strength of 88±2 MPa for load-bearing parts
• Bending modulus of 3100±150 MPa for rigid, stiff prints
• Izod impact strength of 60±4 kJ/m² (X-Y) for impact resistance
• Wide printing speed range of 40-250 mm/s
• Nozzle range of 240-270 ℃ and bed range of 65-70 ℃ for clear setup guidance
• Heat deflection temperature of 67 ℃ (0.45 MPa) and Vicat softening temperature of 74 ℃
• ACE compatible, for desktop FDM printers with a hardened steel nozzle (0.4 mm or above)

Specifications

• Filament Material: PETG-CF (carbon fiber reinforced PETG)
• Density: 1.32 g/cm³
• Melt Flow Index: 14.1±1.6 g/10 min (190℃/2.16kg)
• Tensile Strength: 54±2 MPa
• Young's Modulus: 2550±100 MPa
• Elongation at Break: 12±1%
• Bending Strength: 88±2 MPa
• Bending Modulus: 3100±150 MPa
• Izod Impact Strength: 60±4 kJ/m² (X-Y)
• Melting Temperature: 221 ℃
• Vicat Softening Temperature: 74 ℃
• Heat Deflection Temperature: 67 ℃ (0.45 MPa)
• Nozzle Temperature Range: 240-270 ℃
• Bed Temperature Range: 65-70 ℃
• Printing Speed Range: 40-250 mm/s
• Drying Temperature & Time: 60-65 °C, 6-8 h (convection oven)
• Compatible Printers: Desktop FDM 3D printers with a hardened steel nozzle (0.4 mm or above); ACE compatible
• Material Type: FDM Filament
• Colour: Syrup Brown (#99403A)
• Net Weight: 1 kg

What's in the Box

• 1 x Anycubic PETG-CF Filament – Syrup Brown

Why ANYCUBIC

Choose ANYCUBIC for a 3D Printer Materials with clearly documented capabilities and specifications, making it easier to select the right fit with confidence.
